제품특징
- Stainless steel construction
- Fully environmental protection
- Material
- Stainless steel construction
- Cable
- Braided shiild 4wire round cable width PVC - jacket
- Cable Grand Explosion-proof approved
| Max. Capacity | kgf | 0.5, 1, 2, 3, 5 tf |
|---|---|---|
| Rated output | mV/V | 2.0 ± 0.005 |
| Zero balance | mV/V | 0 ± 0.2 |
| Combined error | %RO | 0.03 |
| Repeatability | %RO | 0.01 |
| Creep (30min.) | %RO | 0.03 |
| Temperature effect on | ||
| Zero value | %RO/10℃ | 0.028 |
| Output value | %RO/10℃ | 0.014 |
| Excitation | ||
| Recommended | V | 10 |
| Maximum | V | 15 |
| Resisitance | ||
| Input | Ω | 350 ± 3.5 |
| Output | Ω | 350 ± 3.5 |
| Insulation | MΩ | ＞ 2,000 @ 50V DC |
| Compensated temp. range | ℃ | -10 ~ +40 |
| Operating temp. range | ℃ | -20 ~ +80 |
* 표를 가로로 드래그 해서 확인하세요.
