제품특징
- Robust design and easy installation
- Strong against shock or side force
- Material
- Paint Stainless Stell
- Cable
- Braided shield 4-wire round cable width PVC-jacket
| Max. Capacity | kgf | 25, 30 tf |
|---|---|---|
| Rated output | mV/V | 2.0 ± 0.004 |
| Zero balance | mV/V | 0.0 ± 0.03 |
| Combined error | %RO | 0.03 |
| Repeatability | %RO | 0.02 |
| Creep (30min.) | %RO | 0.03 |
| Temperature effect on | ||
| Zero value | %RO/10℃ | 0.03 |
| Output value | %RO/10℃ | 0.015 |
| Excitation | ||
| Recommended | V | 10 |
| Maximum | V | 15 |
| Resisitance | ||
| Input | Ω | 820 ± 50 |
| Output | Ω | 700 ± 7 |
| Insulation | MΩ | ＞ 2,000 @ 50V DC |
| Compensated temp. range | ℃ | -10 ~ +40 |
| Operating temp. range | ℃ | -20 ~ +80 |
* 표를 가로로 드래그 해서 확인하세요.
